Talaria Battery 81.4v 22s 4070Wh 50Ah Diablo Molicel P50B 45Kw

EBMX, VTB, Torp & Nuclar Controllers Compatible

Satanically Powerful

Power: Ultimate (45kw)
Range: Very High (4070Kwh 271% Over OEM)
Height: Tall (373mm, needs seat lift or new lid)

Battery Activation Required On Delivery

Talaria Battery 81.4v 22s 4070Wh 50Ah Diablo Molicel P50B 45Kw gives more Volts, More RPM, More top speed. Less Field Weakening required. Less heat.  More gearing to play with!

Talaria Battery 81.4v 22s 4070Wh 50Ah Diablo Molicel P50B 45Kw.  We wanted to make the very best Talaria battery possible. The build list is like a dream: Molicel P50b.  These are the very best and most illusive and expensive cells on the market.  They are under ration from Molicel. Made with pure copper sheet connections. The Hybrid BMS is an ANT 550 BMS (220A/550A).  The exoskeleton case is made from stainless steel 316.

Cells

There are 220 cells in this battery and all have internal resistance. The more resistance, the more heat they produce, until they start to damage.  The Molicel P50b is classed as the worlds premier cell for low resistance for a high  power density (Ah). So with this low resistance, they are able to supply enormous amounts of power without over heating.

Power

This is a Talaria Battery 81.4v 22s 4070Wh 50Ah Diablo Molicel P50B power as limited by the 550A (peak/burst) by the Ant 550 BMS. A genuine constant power of 17.9Kw (220A non stop).

Exoskeleton / Casing

We have upgraded the casing to marine grade 316 stainless steel, so absolutely no rust issues here! Super tough and powder coated inside and out.

Connectors

For the main battery to controller connector we use the same type of plug as used by Talaria, but we use two sets to share “parallel” the power. This reduces heat, transfers load more efficiently and keeps the connectors from overheating.

One direct set of discharge cables goes to the controller via a high capacity QS8 connector using very large 6 AWG cables. This reduces internal resistance and heat build up. A separate second set of discharge cables using the original 8 AWG cable via a Talaria OEM plug connects to the OEM loom via the circuit breaker.

Domestic Electrics

This means all your bike accessories are still powered. Some believe that not using the circuit breaker direct to the controller removes the safety of the circuit breaker. However all our batteries have a full working BMS. Any power shorts or irregular current and the BMS shuts down.  This is much more sensitive and accurate than a mechanical breaker (you may note that the Sur Ron Ultra Bee does not use a circuit breaker and relies on the BMS alone).

Fitting

The battery uses two sets of discharge cables. One to fit the original bikes connector (for Sur Ron we supply an adapter so it can also fit a Talaria). The second goes to an additional cable that we provide that is fixed direct to the controller. This enables the power to be fed “In Parallel” increasing the electrical flow, reducing resistance and reducing harmful heat. It shares the power delivery and takes the strain away from the original loom. These must be connected in a correct order (simple instructions supplied).

For those using a Torp Controller, Torp do not like direct power to the controller via your second cable.  You can either not use the additional power cable we supply (we do not like to remove these as often buyers transfer batteries to another bike) or, if you are worried about your Torp warranty, you can request one of our 2 into 1 convertors in the checkout notes.  Details of the adapter can be found here:https://electroncycles.com/product/two-into-one-converter-qs8-supra-d6-talaria-oem-any-combination-available/

Battery Compartment Lids or Lifting Kits

Because of the extra battery height (373mm) minor modification will needed to your bike.

There are several options:

#1 Fit an aftermarket battery compartment lid found here: https://electroncycles.com/product/talaria-battery-compartment-injection-moulded-battery-lid-to-fit-taller-batteries-not-3d-printed/

#2 Remove the battery plastic base tray in the bike (simply remove the 5 small allen key bolts from the top looking down) and fit our 5mm spacer between the metal battery lid catch and the lid (spacers provided)

#3 Seat Lift Kit option: https://www.electroncycles.co.uk/product/talaria-mx-seat-lift-kit-black-full-e-charged/

Specification Talaria Battery 81.4v 22s 4070Wh 50Ah Diablo Molicel P50B 45Kw

Connecting to Bike

When connecting the Talaria Battery 81.4v 22s 4070Wh 50Ah Diablo Molicel P50B 45Kw to the bike, and to avoid a spark, turn the red trip switch on the bike to off. Connect the older original power cable and then turn the red trip to on. Then connect the new power leads. Removing the battery has no special order.

Battery Charging

First time charging is VERY important. Always connect the charger to the battery with the charger powered up at the mains first. This will stop a “Connection Spark”. The battery needs a “Balance Charge” on first charge. Please charge for 12 hours first time.  Always charge your battery in a safe place and never unsupervised.

Charger Not Included

Our recommended charger for this battery is:  https://electroncycles.com/product/charger-81v-92-4v-6a/

This Battery will not work with an original standard Talaria Controller

Bike Not Included
